Select	Part Number	V_CES / V_RRM	I_C / I_F	Configuration	Housing	I_{FSM tp₁}	Technology	V_Isol	L_sCE / L_sAC	RoHS & REACH status

+	5SNA1500E330305	3300	1500	1 x IGBT	HiPak2 LV W = 140 mmL = 190 mmH = 38 mmw = 138 mml = 188 mm		SPT+	6000	8e-9
+	5SNA0800N330100	3300	800	1 x IGBT	HiPak1 LV 40mm W = 130 mm L = 140 mm H = 38 mm w = 128 mm l = 138 mm		SPT	6000	15e-9
+	5SFG1150B12x001	1200	740	SiC Phase leg +T	RoadPak B W = 70 mmL = 110 mmH = 30.5 mmw = 48.2 mml = 42.6 mm		SiC Gen3+	3300	5e-9
+	5SNA1200G450300	4500	1200	1 x IGBT	HiPak2 HV W = 140 mmL = 190 mmH = 48 mmw = 138 mml = 188 mm		SPT+	7400	18e-9
+	5SNA1200G450350	4500	1200	1 x IGBT	HiPak2 HV W = 140 mmL = 190 mmH = 48 mmw = 138 mml = 188 mm		SPT+	10200	18e-9
+	5SNG0300Q170300	1700	300	Phase leg	62Pak W = 61.4 mm L = 106.4 mm H = 30.8 mm w = 61.4 mm l = 106.4 mm		SPT++	4000	20e-9
+	5SNA1000J450300	4500	1000	1 x IGBT	HiPak1 HV W = 130 mm L = 140 mm H = 48 mm w = 128 mm l = 138 mm		SPT++	7400	27e-9

Select	Part Number	V_DRM / V_RRM	I_{T(AV)M T_C1} / I_{F(AV) T_C1}	Configuration	Housing	I_{TSM VR t_p1}	RoHS & REACH status

+	5SEG0540T1820	1800	630	Thy / Diode Phase leg	60Pak W = 60 mm L = 150 mm H = 52 mm w = 60 mm l = 124 mm
+	5STP16F2810	2800	1500	PCT	F D = 75 mm H = 26 mm d = 47 mm
+	5STP26N6500	6500	2880	PCT	N D = 150 mm H = 35 mm d = 100 mm	40.0e3
+	5STP40X6500	6500	3780	PCT	X

Select	Part Number	V_DRM	I_{T(AV)M TC1}	Configuration	Housing	V_DC	I_{TGQM VD1}	d_P	RoHS & REACH status

+	5SHY60L6500	6500	1900	Asym IGCT +T	L W = 173 mm L = 445 mm D = 120.5 mm H = 26 mm d = 85 mm	4000	6000	85e-3
+	5SHX19L6020	5500	840	RC IGCT	L W = 173 mm L = 445 mm D = 120.5 mm H = 26 mm d = 85 mm	3300	1800	85e-3

Select	Part Number	V_CES / V_RRM	I_C / I_F	Configuration	Housing	I_{FSM tp₁}	Technology	V_Isol	L_sCE / L_sAC	RoHS & REACH status

+	5SDF17L6510	6500	2380	Diode SDF for IGBT	L3	37300
+	5SDF34L4520	4500	2690	Diode SDF for IGCT	L3	40e3

Select	Part Number	V_RRM	I_{F(AV) T_C1}	Configuration	Housing	I_{FSM t_p1}	RoHS & REACH status

+	5SEG0540T1821	2200	889	Diode / Diode Phase leg C	60Pak W = 60 mm L = 150 mm H = 52 mm w = 60 mm l = 124 mm
+	5SDD40H4000	4000	3847	Diode SDD Rect	H2 D = 102 mm H = 26 mm d = 63 mm
+	5SED0890T2260	2200	889	Diode / Diode Phase leg C	T D = 58.5 mm H = 20 mm d = 34 mm
+	5SDD57N6500	6500	5850	Diode SDD Rect	N D = 150 mm H = 35 mm d = 100 mm

Select	Part Number	V_RRM	I_{F(AV) T_C1}	Configuration	Housing	I_{FSM t_p1}	RoHS & REACH status

+	5SDD92Z0401	400	9244	Diode SDD Weld	Z1 D = 53 mm H = 5 mm d = 47 mm	64000
+	5SDD0120C0400	400	11350	Diode SDD Weld	C D = 75.5 mm H = 8 mm d = 57 mm	85000
